5 Ton -10 Ton Diesel Forklift Truck

Baoomax 5ton -10ton Diesel Forklifts truck are built to conquer the challenges of industrial environments with ease. Its solid frame, reinforced components, and rugged design ensure exceptional durability and longevity, making it the ideal choice for demanding applications in warehouses, distribution centers, manufacturing facilities, and more.

Product Description

Equipped with advanced power systems, Baoomax heavy counterbalance Diesel Forklift offers smooth and responsive control for accurate maneuverability. Its intuitive controls and ergonomic design empower operators to navigate confined spaces, narrow aisles, and congested areas with ease, ensuring optimal productivity and safety. The forklift’s precise steering and responsive braking systems enable seamless operation, contributing to enhanced efficiency and minimizing the risk of accidents or damage.

5 Ton -10 Ton Diesel Forklift Truck specification

Model FL50DF FL70DF
Load capacity 5000 kg 7000 kg
Load center 500 mm 500 mm
Power type Diesel Diesel
Max. lifting speeds(with load) 375 mm/s 440 mm/s
Max. driving speeds(with/without load) 20/40 km/h 22/26 km/h
Max towering (with load) 31/18 kn 52 kn
Grade ability(with load) 15/20% 20/25%
Lifting height 3000 mm 3000 mm
Free lift 150 mm 210 mm
Tilting angles(forward-backward) 6/12 6°/12°
Min. turning radius 3000 mm 3450 mm
Min. Right angle aisle width 2750 mm 3090 mm
Min. under-clearance 170 mm 230 mm
Overall length(including fork) 4350 mm 4800 mm
Overall width 1400 mm 1995 mm
Overall height(mast lowered) 2330 mm 2500 mm
Overall height(mast extender) 4265 mm 4420 mm
Overall height to overhead guard 2330 mm 2420 mm
Fork overhang 565 mm 632 mm
Wheel base 2150 mm 2250 mm
Front tread 1180 mm 1470 mm
Rear tread 1190 mm 1700 mm
Front tire 300-15 8.25-15-14
Rear tire 7.00-12 8.25-15-14
Total weight 6800 kg 9500 kg
Fork width 150 mm 150 mm
Fork thickness 55 mm 65 mm
Backrest height 1275 mm 1365 mm
Fork length 1220 mm 1220 mm
Engine model 4JR3 Chaochai6102-BG/QC4115G
Rated power 59 kw 80.9/85 kw
Rotate speed at rated power 2200 rpm 2500/2300 rpm
Max. Torque 300 nm 353/400 nm
Rotate speed at max. Torque 1800 rpm 1650/1600-1800 rpm
Type of power shift Tor-con Tor-con
